SolarGPT — geographic drill-down and reprojected raster overlays

SolarGPT is where the family spent the most time learning to work with geographic data. On the surface it's solar-roofing lead generation with a geographic drill-down (state → county → city → ZIP) and a quote form. Underneath, it's a small GIS: choropleths bound to live KPIs, and actual raster processing in the browser. This is the project whose panel and data patterns seeded the others (and it spans two subdomains — solar and energy).

Coloring the map from the data

The base map is stripped down — labels off, roads off, water tinted — so the only thing carrying color is the data itself. A GeoJSON layer sits on top, colored per county from a KPI lookup, and clicking a county drills down through the router:

// src/components/GEAChoropleth.tsx
import { APIProvider, Map, useMap } from "@vis.gl/react-google-maps";
import { GEA_COLORS, getGeaColor } from "@/lib/gea-colors";

const MAP_STYLE = [
  { featureType: "all", elementType: "labels", stylers: [{ visibility: "off" }] },
  { featureType: "water", elementType: "geometry", stylers: [{ color: "#dbeafe" }] },
  { featureType: "landscape", elementType: "geometry", stylers: [{ color: "#f8f8f8" }] },
  { featureType: "road", elementType: "all", stylers: [{ visibility: "off" }] },
  { featureType: "poi", elementType: "all", stylers: [{ visibility: "off" }] },
];

A fixed color ramp (GEA_COLORS / getGeaColor) and a darkenHex helper for the borders keep every map drawing from the same set of colors.

Reprojecting solar-flux rasters in the browser

The most technically involved feature: overlaying Google's solar-flux data, which arrives as GeoTIFF rasters in whatever CRS the tile was authored in (often UTM). SolarGPT decodes the TIFF, reads its geokeys, and reprojects the bounding box to WGS84 with proj4 — all client-side, with the heavy libraries dynamically imported so they never touch the initial bundle:

// src/components/SolarFluxOverlay.tsx
const [{ fromArrayBuffer }, geokeysToProj4Mod, proj4Mod] = await Promise.all([
  import("geotiff"),
  import("geotiff-geokeys-to-proj4"),
  import("proj4"),
]);

const tiff = await fromArrayBuffer(fluxBuf);
const image = await tiff.getImage();

// Reproject the bounding box from the GeoTIFF's native CRS to WGS84
const geoKeys = image.getGeoKeys();
const projObj = geokeysToProj4.toProj4(geoKeys);
const projection = proj4(projObj.proj4, "WGS84");
const box = image.getBoundingBox();
const sw = projection.forward({ x: box[0] * projObj.coordinatesConversionParameters.x, y: box[1] * projObj.coordinatesConversionParameters.y });

const rasters = await image.readRasters();

A second 1-bit mask raster (roof / not-roof) is decoded the same way and applied per-pixel, so the flux only paints on actual rooftops. This is real GIS work happening in a Next.js client component — no server-side geoprocessing tier.

Why it matters

SolarGPT proves the family can handle genuinely hard data — coordinate systems, raster masks, tens of thousands of geographic features — without a specialized backend. The lessons (curated color ramps, panel-beside-map, pay-for-what-you-use imports) show up everywhere else in NYSgpt.
